VIVOTEK CC8160(HS) 2MP height-strip network camera
Technical Specification
Features:
- Make: VIVOTEK
- Model code: CC8160(HS)
- Chip Inch Size: 1/3 inch
- Resolution: 1920 x 1080 resolution
- Digital (DSP): 1
Additional info:
30 fps @ 1920x1080 180° Horizontal Panoramic View Low-Profile Design Built-in 802.3af Compliant PoE Smart Stream II to Optimize Bandwidth Efficiency WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments Supports ONVIF Standard to Simplify Integration and Enhance Interoperability Height Strip Design for Eye-level Video Surveillance
Read more| Make | VIVOTEK |
|---|---|
| Manufacturer | VIVOTEK |
| Category | IP Cameras products |
| Model code | CC8160(HS) |
|
Chip Inch Size: 1/3 inch Resolution: 1920 x 1080 resolution Digital (DSP): 1 Sensitivity Lux: 0.22 Auto Iris: 1 Direct Drive: 1 Focal Length mm: 1.66 Wide Dynamic Range: 1 Back Light Compensation: 1 Auto Gain Control: 1 White Balance: 1 Electronic Shutter Range: 1/5 sec. to 1/32,000 sec. S/ N (Signal/ Noise) Ratio dB: 58.2 Compression Type: H.264, MJPEG |
|
| Electrical Specifications |
Voltage: PoE Power Consumption: 2.01 W |
| Network Properties |
Image Frame Rate: 30 fps Interface: 10 Base-T/100 Base-TX Ethernet (RJ-45) Network Protocols: 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP |
| Physical Specifications |
Weight g: 94 Dimensions mm: 28 x 49 x 866 |
| Environmental Specifications | Operating Temperature oC: 0 ~ 40 C (32 ~ 104 F) |
| System Requirements |
Operating System: Microsoft Windows 8/7, Mac 10.12 (Chrome only) Web Browser: Chrome 58.0 or above, Internet Explorer 10/11 |
| Additional info |
|
