ImmerVision Low -Light Navigation Camera Module For Machine Perception

Product Profile

A UNIQUE DESIGN THAT MAXIMIZES BOTH LOW-LIGHT SENSITIVITY AND IMAGE QUALITY

Designed in Immervision’s InnovationLab by multidisciplinary scientists, optical designers, and image processing engineers, this camera module satisfies requirements of operating in low-light conditions while delivering optimal image quality.

Platforms equipped with this innovative technology can operate from dusk-to-dawn, both outdoors and indoors. It is suitable for use by human operators and/or the artificial intelligence (AI) and machine learning (ML) systems used in fully autonomous vehicles.

OFF-THE-SHELF AND OUT-OF-THE-BOX

This camera module is driver ready for industry’s leading robotic platform and flight controller. The plug-and-play solution gives access to Immervision’s image processing software capability directly ported on the platform.

CUSTOM DEPLOYMENTS

Easy to customize, this camera module can also be used for other applications, including robots, land vehicles, and water vessels.

Read more

Technical Specification

Make ImmerVision
Manufacturer ImmerVision
Category IP Cameras products
Model code Low -Light Navigation Camera Module
Chip Inch Size: 1/2.8 inch
Colour Type: Colour
Resolution: 2592 x 1944 px resolution
Focal Length mm: 1.38 mm
Network Properties Interface: MIPI 4 Lane
Physical Specifications Weight g: 4.7
Dimensions mm: 16.0 x 16.0 x 18.65
Environmental Specifications Operating Temperature oC: -30 ~ +85 C (-22 ~ +185 F)
Protection: IP67
Additional info
  • LOW-LIGHT - High performance in low-light conditions, allows secure navigation.
  • WIDE-ANGLE - Wide-angle panomorph lens with Smart Pixel Management, optomizes image quality and 190° Field of View for obstacle avoidance.
  • VARIOUS ENVIRONMENTS - Front lens element in glass for usage in various environments, outdoors and indoors.
  • OFF-THE-SHELF - Solution is ready for implementation while being easily customizable to application requirements.
  • LIGHT WEIGHT - Small footprint and light weight for low impact on battery consumption.
  • OTHER APPLICATIONS - Well suited for other navigation applications such as land vehicles, water vessels, robots, etc.
