Hikvision DS-6701HWI 1-channel IP video encoder
Technical Specification
Features:
- Make: Hikvision
- Model code: DS-6701HWI
- Video Inputs: 1 channels
- Data Input: DataInput
- Audio Input: Audio Input
Additional info:
Hikvision DS-6701HWI IP video encoder features H.264/MPEG4/MPEG2/MJPEG encoding standards, one independent PoE network interfaces, multiple network protocols, including IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP support and multiple PTZ protocols.
Read more| Make | Hikvision |
|---|---|
| Manufacturer | Hikvision |
| Category | IP Cameras products |
| Model code | DS-6701HWI |
|
Video Inputs: 1 channels Data Input: DataInput Audio Input: Audio Input Alarm Input: Alarm Input Compression Type: H.264/ JPEG /M-JPEG/MPEG-4 Network Protocols: IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, hkDDNS, NTP, RTSP, RTP/RTCP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SOCKSv4/v5, PSIA, OnVIF, Hik CGI, netFilter Interface: 1 RJ-45 10 M / 100 Mbps adaptive Ethernet interface (PoE) Image per second (IPS): 30 fps Control: PTZ |
|
| Physical Specifications |
Dimensions mm: 80 x 39 x 90 Weight g: <500 |
| Electrical Specifications |
Power Consumption: <5 W Voltage: 12 V DC |
| Environmental Specifications |
Operating Temperature oC: -10 ~ +55 C (140 ~ 131) Operating Humidity %: 10 ~ 90 |
| Additional info |
Hikvision DS-6701HWI IP video encoder features H.264/MPEG4/MPEG2/MJPEG encoding standards, one independent PoE network interfaces, multiple network protocols, including IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP support and multiple PTZ protocols. |
