Ernitec HO-S 321 CCTV camera
Technical Specification
Features:
- Make: Ernitec
- Model code: HO-S 321
- Series: LunaVision Series
- Chip Inch Size ": 1/2 inch
- Colour Type: Colour
Additional info:
Shock test: 60G in 3 dimensions, repeated 3 times. Bump test: 10G in 3 dimensions, repeated 100 times. Lifetime operation min 120 000 hours. Aluminium housing. Twin fan air-cooled CCD. On screen display. Integration: OFF / 2F / 4F / 8F / 16F / 32F / 64 field.
Read more| Make | Ernitec |
|---|---|
| Manufacturer | Ernitec A/S |
| Category | IP Cameras products |
| Model code | HO-S 321 |
| Series | LunaVision Series |
|
Chip Inch Size ": 1/2 inch Colour Type: Colour Resolution TVL: 540 Digital (DSP): Digital Auto Iris: AI Direct Drive: DD Sensitivity lux: 0.0006 @ 30 IRE Back Light Compensation: BackLightCompensation Auto Gain Control: AutoGainControl White Balance: WhiteBalance Electronic Shutter range: 1/60 ~ 1/10,000 S/ N (Signal/ Noise) Ratio dB: > 50 Synchronisation: Internal/External Signal Mode: PAL Video Output: 1.0 Vp-p, 75 Ohm |
|
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: 3 W |
| Physical Specifications |
Dimension mm: 120 x 76 x 56 Weight g: 480 |
| Environmental Specifications |
Operating Temperature oC: -10 ~ +70 Operating Humidity %: 0 ~ 95 |
| Additional info | Shock test: 60G in 3 dimensions, repeated 3 times. Bump test: 10G in 3 dimensions, repeated 100 times. Lifetime operation min 120 000 hours. Aluminium housing. Twin fan air-cooled CCD. On screen display. Integration: OFF / 2F / 4F / 8F / 16F / 32F / 64 field. |
