Bosch LTC0335/50 monochrome camera with auto detection of lens type
Technical Specification
Features:
- Make: Bosch
- Model code: LTC0335/50
- Chip Inch Size ": 1/3 inch
- Colour Type: Monochrome
- Resolution TVL: 380
Additional info:
The LTC 0335 series are compact, rugged, 1/3-inch image format digital monochrome CCD cameras. Their superior sensitivity and resolution provide optimal performance in virtually all environments.
Read more| Make | Bosch |
|---|---|
| Manufacturer | Bosch Security Systems |
| Category | IP Cameras products |
| Model code | LTC0335/50 |
|
Chip Inch Size ": 1/3 inch Colour Type: Monochrome Resolution TVL: 380 Digital (DSP): Digital Sensitivity lux: 0.024 Lens Mount: C/CS mount Picture Elements HxV: 512 x 582 Back Light Compensation: BackLightCompensation Auto Gain Control: AutoGainControl Electronic Shutter range: 1/50 ~ 1/500,000 S/ N (Signal/ Noise) Ratio dB: 50 Synchronisation: Line-lock Signal Mode: CCIR Video Output: 1.0 Vp-p, 75 Ohms |
|
| Electrical Specifications |
Voltage: 230 V AC Power Consumption: 4 W |
| Physical Specifications |
Dimension mm: 58 x 66 x 122 Weight g: 450 |
| Environmental Specifications |
Operating Temperature oC: -20 ~ +50 Operating Humidity %: 5 ~ 93 |
| Additional info |
The LTC 0335 series are compact, rugged, 1/3-inch image format digital monochrome CCD cameras. Their superior sensitivity and resolution provide optimal performance in virtually all environments. |
